The Automatic Water Level Controller Board for Industrial Steam Iron Boilers is a specialized electronic control module designed to automatically monitor and manage water levels in compatible industrial steam generators, steam irons and garment boiler systems.

The controller works with the boiler’s water-level sensing probes to detect when the water level drops and activate the connected water pump for automatic refilling. It helps maintain a consistent water supply for continuous steam generation while helping protect the boiler from low-water dry-running conditions and overfilling.

This replacement controller board is suitable for compatible industrial steam ironing and garment-finishing equipment, including systems from Magneto, Silver Star, Hashima, Veit and Naomoto, as well as compatible 3L–5L commercial steam boiler systems.

WHAT YOU GET

• 1 × Automatic Water Level Controller Board
• Electronic water-level control PCB
• Designed for compatible industrial steam iron/boiler systems

KEY FEATURES

Automatic Water-Level Monitoring

The controller continuously monitors the boiler’s water level through the connected water-level probes. When the water drops below the required level, it can activate the water pump to refill the boiler.

Automatic Pump Activation

The board is designed to control the connected water-pump operation according to the boiler water-level signal, helping maintain the required water level during continuous steam production.

Helps Prevent Dry Running

Maintaining an adequate water level helps protect boiler heating elements from operating without sufficient water.

Helps Prevent Overfilling

Water-level sensing helps regulate the filling cycle so the boiler does not continue filling beyond the required operating level.

LED Status Indicators

Integrated LED indicators provide convenient visual information about conditions such as:

• Power supply
• Water-level status
• Pump operation
• Controller activity

High-Temperature & Moisture-Resistant Design

The electronic components are intended for demanding industrial garment-steaming environments where elevated temperature, moisture and continuous operation may be present.

Direct Replacement Application

Designed as a replacement electronic water-level controller for compatible industrial steam iron and boiler systems. Check the original board, terminal layout and electrical specifications before installation.

COMPATIBLE STEAM IRON & BOILER SYSTEMS

Magneto Steam Iron Boilers

Suitable for compatible Magneto industrial steam iron boiler systems using the corresponding water-level control arrangement.

Silver Star Steam Iron Boilers

Suitable for compatible Silver Star industrial steam systems where the original controller has the matching configuration.

Hashima Steam Systems

Designed for compatible Hashima industrial garment-steaming equipment with the appropriate water-level sensing and pump-control setup.

Veit Steam Systems

Suitable for compatible Veit steam boiler systems where the electronic board specifications and terminal configuration match.

Naomoto Steam Systems

Suitable for compatible Naomoto industrial steam iron and boiler systems with the corresponding controller arrangement.

3L–5L Commercial Steam Boilers

Suitable for compatible commercial garment steam generators in the 3L–5L capacity range, subject to the original controller’s electrical and terminal specifications.

महत्वपूर्ण: Compatibility depends on the PCB configuration, terminal layout, sensor type, supply voltage, pump connection and boiler wiring, not only on the machine brand.

HOW THE WATER LEVEL CONTROLLER WORKS

The controller uses the boiler’s water-level sensing probes to determine the condition of the water inside the tank.

1. Water Level Drops

When the boiler water falls below the required sensing level, the controller detects the low-water condition.

2. Pump Activation

The controller sends the appropriate control signal to activate the connected water pump.

3. Boiler Refilling

The pump supplies water to the boiler until the required water level is restored.

4. Pump Stop

Once the appropriate water-level signal is detected, the controller stops the filling cycle.

5. Continuous Steam Production

Maintaining the correct boiler water level helps support continuous steam generation during industrial garment pressing.

COMMON APPLICATIONS

This water-level controller board is useful for:

• Industrial steam irons
• Steam boiler systems
• Industrial garment pressing machines
• Commercial steam generators
• Garment finishing equipment
• Tailoring and pressing units
• Laundry pressing systems
• Textile production facilities
• Industrial steam ironing stations
• 3L–5L steam boiler systems

INDUSTRIAL GARMENT APPLICATIONS

The controller can support steam systems used for:

• Shirt pressing
• Trouser pressing
• Suit pressing
• Jacket pressing
• Coat pressing
• Uniform pressing
• वस्त्र की फिनिशिंग
• Wrinkle removal
• Textile pressing
• Commercial laundry pressing

PRODUCT SPECIFICATIONS

*Capacity alone does not guarantee compatibility. Verify the original board and electrical specifications before installation.

IMPORTANT COMPATIBILITY CHECK

Before purchasing this replacement controller board, compare your existing board for:

• PCB dimensions
• Terminal positions
• Terminal spacing
• Number of terminals
• Supply voltage
• Pump output specification
• Sensor/probe connection
• वायरिंग व्यवस्था
• Boiler model
• Original controller part number, if available

Please verify the shape, terminal layout and electrical specifications of your existing controller board before purchasing.

Do not connect the board based solely on wire color. Always follow the original machine wiring diagram and controller specifications.

SAFETY INFORMATION

This controller operates as part of an industrial steam boiler system containing electricity, hot water and pressurized steam.

For safe operation:

• Disconnect mains power before servicing.
• Allow the boiler to cool before opening or servicing it.
• Do not bypass water-level sensors.
• Do not operate the boiler without adequate water.
• Do not modify the PCB circuit.
• Verify the pump and power-supply ratings.
• Use proper electrical insulation and earthing.

FREQUENTLY ASKED QUESTIONS

What is an automatic water level controller board for a steam iron boiler?

It is an electronic control board that monitors boiler water levels through sensors or probes and controls the water pump to maintain the required water level for steam generation.

What does this controller board do?

It monitors the boiler water level and can automatically activate the connected water pump when the water level becomes low and stop the filling cycle when the required level is reached.

Can this board prevent boiler dry running?

The controller is designed to help maintain the required water level and reduce the risk of low-water operation. Actual protection depends on the complete boiler wiring, sensors, heating-control system and installation.

Can it prevent boiler overfilling?

The water-level sensing system is designed to control the filling cycle and help prevent excessive filling when correctly installed and configured.

Is this suitable for Magneto steam irons?

It is suitable for compatible Magneto industrial steam iron boiler systems where the original controller configuration matches.

Can this be used on Veit machines?

It may be used on compatible Veit steam boiler systems where the controller specifications and wiring arrangement match.

Is it compatible with Naomoto steam irons?

It is suitable for compatible Naomoto industrial steam boiler systems with the required water-level controller configuration.

Does the board include water-level sensors?

The product is supplied as a controller board. Sensor/probe availability should be confirmed from the actual package supplied. If sensors are not listed separately in the product package, the original boiler sensors may need to be reused.

How do I know whether this board will fit my boiler?

Compare the PCB dimensions, terminal spacing, terminal count, supply voltage, pump connection, sensor connection and wiring arrangement with your existing controller.
