उत्पाद वर्णन
The ST-6 Boiler Buzzer Board is an electronic water-level alarm and indicator PCB designed for compatible industrial steam iron boilers, steam generators and garment pressing equipment.
The board monitors the boiler’s water-level sensing circuit and provides an audible buzzer alert and LED indication when the water level falls below the required operating level. This helps alert the operator to a low-water condition and can help reduce the risk of boiler heating elements operating without sufficient water.
The ST-6 board is intended for compatible ST-6 boiler systems and can also be used in matching industrial steam boiler configurations from brands such as Magneto, Silver Star, Hashima, Veit and Naomoto, including compatible 3L/5L commercial pressing units.
WHAT YOU GET
- 1 × ST-6 Boiler Buzzer Board
- Electronic water-level alarm PCB
- Integrated buzzer circuit
- LED indicator circuit
KEY FEATURES
Audible Low-Water Alarm
The integrated high-output buzzer provides an audible warning when the connected boiler’s water level reaches the configured low/critical sensing condition.
This gives the operator an immediate indication that the boiler requires attention or water replenishment.
LED Water-Level Indicators
Built-in LEDs provide visual information about the controller status, such as:
- शक्ति
- Low-water warning
- Water-level condition
- Pump/activity status
Helps Protect Against Low-Water Operation
The alarm alerts the operator when the water level falls below the required probe level, helping reduce the possibility of continuing boiler operation without adequate water.
The actual heating-element protection depends on the complete boiler control system and wiring.
Automatic Alarm Reset
When the water supply is restored and the sensing probe detects the safe operating level, the alarm can reset automatically in compatible ST-6 configurations.
Industrial Electronic Construction
Designed for use in industrial garment-steaming environments where heat, moisture and repeated operation are present.
Direct Replacement Application
Designed around the ST-6 boiler buzzer/alarm board configuration, making it suitable as a replacement for a faulty or damaged compatible board.
Always compare the original board’s terminal arrangement, mounting dimensions and electrical specifications before installation.
ST-6 COMPATIBLE BOILER SYSTEMS
The board is primarily intended for compatible ST-6 industrial steam boiler systems.
It can be suitable for matching boiler configurations used with:
- Industrial steam irons
- Steam generators
- Garment pressing boilers
- Commercial steam ironing units
- Laundry pressing equipment
- Textile finishing equipment
BRAND COMPATIBILITY
The board can be used in compatible steam boiler systems associated with:
बिजली की शक्ति उत्पन्न करने का यंत्र
Suitable for compatible Magneto industrial steam boiler and pressing systems using the corresponding ST-6-type alarm configuration.
Silver Star
Suitable for compatible Silver Star steam ironing systems where the board’s wiring and terminal configuration match.
Hashima
Suitable for compatible Hashima industrial steam boiler systems with the corresponding water-level alarm circuit.
Veit
Suitable for compatible Veit garment pressing equipment where the original alarm board specification matches.
Naomoto
Suitable for compatible Naomoto industrial steam systems with the corresponding ST-6-style water-level alarm arrangement.
3L / 5L Commercial Steam Boilers
Suitable for compatible 3L and 5L industrial steam boiler systems, subject to matching electrical and PCB specifications.
Brand and boiler capacity alone do not guarantee compatibility. Verify your existing board before ordering.
HOW THE ST-6 BOILER BUZZER BOARD WORKS
The board works with the boiler’s existing water-level sensing probes.
1. Normal Water Level
When the boiler water is at the safe operating level, the board remains in its normal monitoring state.
2. Water Level Drops
When the water falls below the designated sensing point, the board detects the low-water condition.
3. Audible Warning
The integrated buzzer activates to alert the operator that the boiler water level requires attention.
4. LED Warning
The corresponding indicator LED provides a visual warning of the detected condition.
5. Water Replenishment
Once the boiler is refilled and the sensing probe detects the safe water level, the alarm can reset automatically in compatible configurations.
COMMON APPLICATIONS
The ST-6 buzzer board is suitable for compatible:
- Industrial steam irons
- Steam boiler machines
- Steam generators
- Garment pressing equipment
- Commercial ironing units
- Laundry pressing machines
- Textile finishing equipment
- Tailoring pressing units
- Garment manufacturing facilities
- Industrial steam ironing stations
BENEFITS
Using a functioning water-level alarm board helps provide:
- Immediate low-water notification
- Audible operator warning
- Visual LED indication
- Easier boiler monitoring
- Reduced risk of unnoticed low-water conditions
- Automatic alarm reset in compatible systems
- Convenient replacement of a faulty ST-6 alarm PCB
PRODUCT SPECIFICATIONS
| विनिर्देश | विवरण |
|---|---|
| उत्पाद का प्रकार | Boiler Buzzer / Water Level Alarm Board |
| नमूना | ST-6 |
| Board Type | Electronic Alarm PCB |
| आवेदन | Industrial Steam Iron Boiler |
| Main Function | Low-Water Warning |
| Alarm | Audible Buzzer |
| Visual Indicator | नेतृत्व किया |
| Reset | Automatic in compatible configurations |
| Compatible Boiler Type | ST-6 / Compatible Steam Boilers |
| Typical Boiler Capacity | 3L / 5L* |
| पैक मात्रा | 1 टुकड़ा |
| कपड़े का प्रकार | N/A |
*Boiler capacity alone does not confirm compatibility.
IMPORTANT COMPATIBILITY CHECK
Before purchasing, compare your existing ST-6 board for:
- PCB size
- Mounting-hole position
- Terminal count
- Terminal spacing
- कनेक्टर प्रकार
- Sensor/probe connections
- Buzzer configuration
- LED arrangement
- Supply voltage
- Wiring layout
- Original board markings
Please verify the original board and terminal configuration before purchasing.
INSTALLATION
This product is an electronic component used in an industrial steam boiler system. Installation should be performed by a qualified technician.
General replacement procedure:
- Switch OFF the boiler and disconnect mains power.
- Allow the boiler and surrounding equipment to cool completely.
- Confirm that no electrical power is present.
- Document the existing wiring before removing the old board.
- Remove the faulty ST-6 board carefully.
- Compare the replacement board with the original.
- Connect the water-level sensing wires according to the original wiring diagram.
- Connect the power and alarm connections correctly.
- Check all terminals and connectors.
- Ensure the PCB is securely mounted.
- Restore power only after completing all safety checks.
- Test the water-level alarm before normal operation.
Never connect the board solely according to wire colour or terminal position. Follow the boiler manufacturer’s wiring arrangement.
SAFETY INFORMATION
Industrial steam boilers can contain mains electricity, high-temperature water, heating elements and pressurized steam.
For safe servicing:
- Disconnect mains power before opening the machine.
- Allow the boiler to cool completely.
- Do not bypass the water-level sensing system.
- Do not operate the boiler without adequate water.
- Do not modify the PCB.
- Verify the correct supply voltage.
- Ensure proper earthing.
- Use suitable electrical insulation.
FREQUENTLY ASKED QUESTIONS
What is an ST-6 Boiler Buzzer Board?
The ST-6 Boiler Buzzer Board is an electronic alarm PCB designed to provide audible and visual warnings when the water level in a compatible industrial steam boiler becomes too low.
What does the ST-6 board do?
It monitors the boiler’s water-level sensing circuit and activates an audible buzzer and LED warning when a low-water condition is detected.
Does the board have a buzzer?
Yes. The board includes an integrated electronic buzzer for audible low-water alerts.
Does it have LED indicators?
Yes. Integrated LEDs provide visual status information for compatible power, water-level and alarm conditions.
Does the alarm reset automatically?
In compatible ST-6 configurations, the alarm can reset once the boiler water is replenished and the sensing probe detects the safe operating level.
Can this board prevent heater dry burning?
The board provides a low-water warning to alert the operator. Actual heater cut-off and dry-burn protection depend on the complete boiler control circuit and its safety devices.
Is this board compatible with Magneto boilers?
It is suitable for compatible Magneto industrial steam boiler systems where the original board configuration matches.
Can I use it with Silver Star steam irons?
Yes, it can be used in compatible Silver Star steam boiler systems when the PCB, terminals and electrical specifications match.
Does it work with Hashima boilers?
It is suitable for compatible Hashima industrial steam boiler systems with the corresponding water-level alarm configuration.
Is it suitable for Veit machines?
It can be used with compatible Veit steam boiler systems where the existing board matches the ST-6 specification.
Can it be used with Naomoto boilers?
Yes, it is suitable for compatible Naomoto industrial steam boiler systems with the corresponding water-level alarm configuration.
Is this suitable for a 3L or 5L steam boiler?
It is intended for compatible 3L/5L commercial steam boiler systems, but boiler capacity alone does not confirm compatibility.
Does this board include the water-level probes?
This product is supplied as the ST-6 buzzer/alarm board. Existing boiler water-level probes may need to be reused unless separately included in the package.
How do I check compatibility?
Compare your existing board’s:
- Model number
- PCB dimensions
- Terminal arrangement
- कनेक्टर प्रकार
- Supply voltage
- Sensor connections
- माउंटिंग पॉइंट्स
- LED/buzzer configuration
Can I install the board myself?
Because the board is installed inside an industrial steam boiler system involving mains electricity and high-temperature/pressurized equipment, installation should be performed by a qualified technician
