Rubber Coupling for Single Needle Lock-Stitch Machine

This rubber coupling for single needle lock-stitch machines connects the motor drive to the main shaft on direct-drive setups and cushions the shock between the two. Best for workshops and garment units fixing a worn, cracked or slipping coupling on a Jack F4/F5/F6, DDL-8700 type or similar machine. It comes in 14 mm and 14.7 mm sizes.

When to Replace the Coupling

• The rubber is cracked, chipped or has hardened.
• The machine knocks when the motor starts or stops.
• The motor runs but the needle lags behind it.
• You are changing the servo motor and want a fresh coupling on the new setup.

Machines It Is Listed For

Check the size and shape of your old coupling before ordering. Shaft sizes differ between machines even within one group.

How It Compares with the 17220007 Rubber Ring

The two are separate parts. See the 17220007 rubber ring coupling for Jack F4/F5/F6 and compare it with your old part.

विशेष विवरण

How to Fit It

1. First, switch off the machine and unplug it.
2. Next, separate the motor from the machine and take out the old coupling.
3. Then fit the new coupling in the same position and size, and refit the motor.
4. Finally, turn the hand wheel by hand to check smooth movement before starting the motor.

पूछे जाने वाले प्रश्न

Which size do I need, 14 mm or 14.7 mm?

Compare your old coupling with the size shown in the options before ordering. The two sizes differ by only 0.7 mm, but a wrong pick can fit loosely and slip. If you cannot tell, check your old part against the product photos first.

Which machines is this coupling for?

It is listed for the Jack F4, F5 and F6, the DDL-8100 to DDL-8700 groups, the 9100 group, and the Brother DA-9270 / 9280 and Jack JK-T9270 / T9280. The sources we checked describe it for direct-drive single needle machines, so confirm the fit on your own machine.

How do I know the rubber coupling is worn?

Look for cracks, chipped lobes or a hardened surface, and listen for a knock when the motor starts or stops. A motor that spins while the needle lags is another usual sign. Rubber is a wear part, so an early swap is cheaper than repairing shaft damage later.

Is this the same as the 17220007 rubber ring?

No. The 17220007 rubber ring is listed separately for Jack F4, F5 and F6 at ₹50. This product is the coupling in 14 mm and 14.7 mm sizes at ₹400 to ₹449, checked on 5 October 2026. Compare the shape with your old part before buying.

Can I pay cash on delivery?

Yes. StitchPartner delivers pan-India with COD available on this coupling. If you are also replacing the motor, see the universal direct-drive servo motor और यह flywheel coupling assembly. Browse more parts in जैक F4 F5 F6 स्पेयर पार्ट्स और DDL-8100/8300/8500/8700 के स्पेयर पार्ट्स.
