114511003 Bobbin Winder Screw for Jack Machine
Short Description
114511003 / 114S11003 bobbin winder fixing screw with SM11/64-28 thread and 10 mm length for compatible industrial single-needle lockstitch machines. Hardened steel construction provides a secure mounting solution for bobbin winder assemblies.
Original price was: ₹25.00.₹10.00Current price is: ₹10.00.
The 114511003 Bobbin Winder Fixing Screw is designed to securely mount compatible bobbin winder assemblies on industrial single-needle lockstitch machines. Its precise SM11/64-28 thread with 10 mm length provides a firm mechanical connection for routine bobbin-winder installation, adjustment, and maintenance.
Key Features
- Precision SM11/64-28 thread specification.
- 10 mm length for the stated bobbin-winder mounting application.
- Hardened carbon-steel construction for repeated tightening and machine use.
- Protective finish helps resist corrosion from oil and workshop conditions.
- Slotted head provides direct screwdriver engagement.
- Designed for bobbin winder assembly mounting.
- Suitable for industrial single-needle lockstitch machines.
- Supplied as 1 piece.
Use Cases
This fixing screw is suitable for:
- Bobbin winder assembly replacement
- Bobbin winder mounting and maintenance
- Industrial sewing machine servicing
- Machine table/head mounting applications
- Garment factory maintenance
- Tailor-shop machine repair
- Boutique production equipment maintenance
- Replacement of worn, stripped, or missing mounting screws
Benefits
Correct Thread Engagement
The specified SM11/64-28 thread provides the required threaded connection for compatible bobbin winder mounting applications.
Secure Assembly Mounting
A properly matched fixing screw helps keep the bobbin winder securely positioned during normal machine operation and vibration.
Durable Steel Construction
The hardened carbon-steel construction is designed to withstand repeated installation, tightening, and routine industrial machine maintenance.
Practical Slotted Head
The single-slot head allows straightforward screwdriver engagement, making the screw convenient for installation and adjustment during servicing.
Replacement for Missing or Damaged Hardware
This is useful when an original bobbin-winder fixing screw has been lost, damaged, stripped, or requires replacement during machine maintenance.
Machine Compatibility
This is a machine-specific industrial sewing machine hardware component compatible with:
| Machine Brand | Compatible Models / Application |
|---|---|
| Jack | JK-9100, JK-A2, JK-A3, JK-A4, JK-A5, F4 |
| Juki | Compatible industrial single-needle lockstitch bobbin winder assemblies |
| Singer | Compatible industrial single-needle lockstitch bobbin winder assemblies |
| Brother | Compatible industrial single-needle lockstitch bobbin winder assemblies |
| Siruba | Compatible industrial single-needle lockstitch bobbin winder assemblies |
| Zoje | Compatible industrial single-needle lockstitch bobbin winder assemblies |
Part Number: 114511003 / 114S11003
Thread: SM11/64-28
Length: 10 mm
Specifications
| Specification | Details |
|---|---|
| Product Type | Bobbin Winder Fixing Screw |
| Part Number | 114511003 |
| Alternate Part Number | 114S11003 |
| Pack Quantity | 1 Piece |
| Thread Specification | SM11/64-28 |
| Length | 10 mm |
| Material | Hardened carbon steel |
| Head Type | Slotted |
| Finish | Protective anti-corrosion finish |
| Application | Bobbin winder mounting |
| Machine Type | Industrial single-needle lockstitch |
| Fabric Type | Not applicable — machine hardware |
How To Use
First, switch off and disconnect the sewing machine before working on the bobbin winder assembly.
Next, position the compatible bobbin winder or mounting bracket correctly against the machine mounting point and align the threaded hole.
Then, insert the 114511003 screw and tighten it with the appropriate screwdriver until the bobbin winder is firmly secured without over-tightening.
Finally, check that the bobbin winder is correctly positioned and operates freely before running the sewing machine at normal production speed.
FAQs
What is the 114511003 screw used for?
The 114511003 is a fixing screw used for compatible industrial sewing machine bobbin winder assemblies. It secures the bobbin winder or related mounting component to the machine structure. The supplied specification identifies it as an SM11/64-28 screw with a 10 mm length.
What is the thread size of 114511003?
The specified thread is SM11/64-28, with a 10 mm length. Thread size is important when replacing a machine screw because a screw with a different thread pitch or diameter may not engage correctly and can damage the threaded mounting hole.
Does this screw fit Jack JK-9100?
Yes. The supplied compatibility information lists the Jack JK-9100 among the compatible machines. It is also specified for Jack JK-A2, JK-A3, JK-A4, JK-A5, and F4 industrial single-needle lockstitch machines.
Is this only for Jack sewing machines?
No. The supplied compatibility information also lists compatible bobbin-winder applications from Juki, Singer, Brother, Siruba, and Zoje. However, compatibility depends on the actual bobbin-winder mounting arrangement and thread specification, so the existing screw should be compared before ordering.
What should I check before buying this screw?
Check the existing screw’s thread specification, length, head style, and mounting application. For this product, the supplied specification is SM11/64-28 with a 10 mm length. Matching these details is more reliable than selecting a screw based only on the machine brand.
Can this screw be used for other parts of a sewing machine?
It should be used for applications where the specified thread and dimensions match. This product is identified specifically as a bobbin winder fixing screw. Using it elsewhere without confirming the thread, length, clearance, and mounting requirements can result in an incorrect fit.
Is the screw suitable for industrial sewing machines?
Yes. It is specified for industrial single-needle lockstitch bobbin-winder assemblies. The hardened carbon-steel construction is intended for mechanical fastening applications where the screw is exposed to regular vibration, maintenance, and repeated machine operation.
Does the screw come with a bobbin winder?
No. The listing is for 1 piece of the fixing screw only. The bobbin winder, bracket, machine head, and other mounting components are not included unless separately stated in the product listing.
How do I install the 114511003 screw?
First, switch off the machine. Next, align the bobbin winder or mounting bracket with its threaded mounting point. Then, insert the screw and tighten it with a suitable screwdriver. Finally, check that the bobbin winder remains properly aligned and rotates or operates freely before production use.
Can I replace a missing bobbin-winder screw with this part?
Yes, when the original application requires the specified SM11/64-28, 10 mm screw configuration. Confirm the thread and length of the missing screw’s mounting position before ordering because visually similar sewing-machine screws can have different thread specifications.
What happens if the wrong thread is used?
A screw with an incorrect thread can fail to engage properly, loosen during machine operation, or damage the threaded mounting point. The correct diameter and thread pitch are therefore important. For this part, verify the SM11/64-28 specification before installation.
Is this screw corrosion resistant?
The supplied product specification states that the screw has a protective anti-rust finish intended to resist oxidation and exposure to sewing-machine oil and workshop conditions. Keeping the screw and surrounding mounting area clean also helps maintain the fastening connection.
