S40375001 / S40376001 / S40377001 Looper for feed of arm machine
Short Description
S40375001 / S40376001 / S40377001 looper for Brother DA-9270/9280 and Jack JK-9270D-13 feed-off-the-arm machines. COD available.
Price range: ₹180.00 through ₹500.00
We added you to this product's waitlist and we'll send you an email when the product is available.
Leave WaitlistThis product is currently sold out.
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
The S40375001 / S40376001 / S40377001 Looper forms the lower chain stitch on Brother DA-9270 / DA-9280 and Jack JK-9270D-13 feed-off-the-arm machines. Best for workshops fixing skipped stitches or thread cutting caused by a worn or damaged looper tip.
Part Details
| Detail | Information |
|---|---|
| Part No. | S40375001 / S40376001 / S40377001 |
| Part Name | Looper |
| Fits | Brother DA-9270, DA-9280; Jack JK-9270D-13 (JK-T9270 / T9280) |
| Machine Type | Feed-off-the-arm industrial machine |
When to Replace It
- Stitches skip even with a fresh needle.
- The looper tip is burred and cuts the thread.
- The looper was bent by a needle strike.
How to Fit It
- First, switch off the machine and remove the throat plate.
- Next, loosen the screw and remove the old looper.
- Then fit the new looper at the same height and tighten.
- Finally, turn the hand wheel to check the looper passes the needles cleanly.
FAQs
Which looper number do I need?
Three part numbers are listed: S40375001, S40376001 and S40377001. Match yours against the old looper before ordering.
Which machines does it fit?
It is listed for the Brother DA-9270 and DA-9280 and the Jack JK-9270D-13.
Is COD available?
Yes. StitchPartner delivers pan-India with COD available.
